HIKMICRO Alpex 4K LITE LRF A40EL Digital Day and Night Vision Rifle Scope - 40mm, 3840x2160px, UHD
- Ultra-compact 30mm tube design weighing under 500g for easy mounting
- 4K UHD day and night vision for crisp detail in all conditions
- Wide field of view of 10.7° × 6.1° / 18.7m × 10.1m at 100m
- Integrated laser rangefinder with ballistic calculator for precise holdover
- One-second startup and 7-hour runtime for reliable field performance
- HIKMICRO Sight app integration for sharing, tracking, and hunt management
Finance Calculator
Representative Calculation
Powered by Autify Digital Ltd
Please note: Due to distribution rights and agreements we can only sell HIK-MICRO products to residents of the UK.
The HIKMICRO ALPEX 4K A40EL is engineered for shooters who demand precision without compromise. Combining a 3840×2160 4K CMOS sensor with a 40mm F2.0 lens, this digital day and night vision scope delivers exceptional image clarity and target recognition in virtually any lighting condition. What sets the A40EL apart is its integrated 1000-meter laser rangefinder with real-time ballistic calculation. This system automatically adjusts reticle holdover based on distance and pellet type—ensuring deadly accuracy whether you're zeroing in on rats at 30 meters or challenging a 90-meter shot with a .25 caliber.
Designed for true around-the-clock use, the A40EL leverages adaptive low-light technology to deliver uncompromised detail at dawn, dusk, and in total darkness. Operate in five vision modes—Day, Night, Auto, Green, and Yellow—tailored for varied terrain and ambient light. With dual imaging frequencies (50Hz in 4K, 100Hz in 1080P), the scope ensures crystal-clear static observation and seamless motion tracking with zero blur. A rapid one-second startup puts the A40EL into action instantly, critical for reactive scenarios in the field.
At just 474g and 25% slimmer than conventional optics, the ALPEX 4K A40EL is purpose-built for airguns and tactical manoeuvrability. The 30mm magnesium-alloy tube form factor ensures universal compatibility and lightweight handling—perfect for stalking pests in tight quarters or carrying across open farmland. Intuitive controls are designed for gloved or wet-hand operation, making it field-ready in every sense.
The A40EL is powered by an internal lithium battery with support for an external rechargeable 18650 cell, providing up to 7 hours of continuous operation. Recoil-activated recording with built-in audio and 32GB of internal EMMC storage allows you to capture every shot with forensic clarity. Whether you're targeting, ranging, recording, or navigating at night, the A40EL is the total field solution for modern airgun hunters.
- Max. Resolution 3840 × 2160
- Frame Rate 50 Hz (4K), 100 Hz (1080P)
- Lens 40 mm, F2.0
- Detection Range (Day) 800 m
- Minimum Focusing Distance 2 m
- Magnification Range 3.5× to 20.5×
- Base Magnification 5.8×
- Zoom Continuous
- Step Values 0.5×, 1×, 2×, 3×, 4×
- Field of View (Degrees) 10.7° × 6.1°
- Field of View (Metres @100 m) 18.7 m × 10.1 m
- Display Type OLED
- Display Size 0.49 inch
- Display Resolution 1920 × 1080
- Image Modes Day, Night, Auto, Green, Yellow
- Exit Pupil 6 mm
- Eye Relief 45 mm
- Dioptre Adjustment -5 D to +5 D
- Video Recording On-board (1920 × 1080)
- Photo Capture Yes
- Audio Recording Yes
- Recoil-Activated Recording Yes
- Standby Mode Yes
- Storage 32 GB built-in EMMC
- Picture-in-Picture (PIP) Yes
- Freeze Zeroing Yes
- Zeroing Profiles 5
- Maximum Recoil Resistance 1000 g / 0.4 ms
- Wi-Fi Hotspot Yes
- Ballistic Calculation Yes
- Click Value 1 click = 1 cm @ 100 m
- Battery Type (Internal) Rechargeable lithium battery
- Battery Type (External) Replaceable & rechargeable 18650 battery
- Operating Time Up to 7 hours (@25°C, Hotspot off)
- Charging Interface USB Type-C (5 VDC / 2 A)
- Direct Charging Supported only with internal battery
- Mounting Standard 30 mm
- Protection Level IP67
- Operating Temperature -30°C to 55°C (-22°F to 131°F)
- Dimensions 280.7 mm × 86.1 mm × 66.3 mm (without eyepiece)
- Weight 474 g (without external battery)
- Laser Rangefinder – Safety Class Class 1
- Laser Rangefinder – Wavelength 905 nm
- Laser Rangefinder – Minimum Measuring Range 3 m
- Laser Rangefinder – Maximum Measuring Range 1000 m
- Laser Rangefinder – Measurement Accuracy ±1 m
- Integrated Laser Rangefinder: Built-in 1000m LRF with ±1m accuracy and real-time ballistic adjustment for pinpoint precision.
- 4K UHD Sensor: 3840×2160 CMOS resolution delivers unmatched clarity in both day and low-light conditions.
- One-Second Startup: Powers on instantly, ensuring you're always ready for rapid target acquisition in the field.
- Dual-Frequency Imaging: 50Hz at 4K and 100Hz at 1080P for blur-free motion and stable observation.
- Ultra-Compact Build: 25% slimmer, just 474g, with a 30mm magnesium-alloy tube for seamless airgun integration.
- 1000m LRF with Ballistic Correction: Built-in laser rangefinder for accurate shooting solutions.
- Adaptive Display Modes: Day, Night, Auto, Green, and Yellow for any environment.
- Pellet Drop Compensation: Supports .177, .22, and .25 calibres for precise shooting.
- 0.49" OLED Screen: Full HD resolution for crisp, high-contrast visuals.
- Recoil-Activated Video: With integrated audio capture.
- 32GB Internal Storage: EMMC memory for recording sessions.
- Extended Runtime: Up to 7 hours continuous use with dual battery support.
- Lightweight Magnesium Body: Ensures durability and long-term performance.
- Seamless Digital Zoom: Up to 20.5x with step or continuous control.
- Instant Operation: One-second boot time for fast deployment.
- HIKMICRO Alpex 4K LITE Digital Day and Night Vision Rifle Scope with LRF
- Quick start guide
- Type-C USB cable
- Lint free cloth
- 1x battery
- 1x battery charger
- Battery: 1 year warranty
- Unit: 3 year warranty
HIKMICRO has a full UK service and technical centre, complete with Hotline: 0203 514 0092 available to assist with any issues.
